Can be used immediately in day-to-day business
MDESIGN basic modules
In addition to basic and expert calculation modules, the Explorer user environment also contains basic modules for daily practice in all subject areas. All basic modules can be used without restriction in the dimensioning and design phase.
Thanks to the link to the online MDESIGN components catalog, product, company and contact data for more than 1,000 manufacturers are always at hand.
Overview of the basic modules for
MDESIGN mechanical
Shaft, axle: Keyway notches - Turned-in shaft - Splined shaft notches - Cross-drilled shafts - Circlip for shafts - Stepped shafts - Friction on bearing/ring journal - design diameter of shaft, axle - Stresses in a beam - Undercuts DIN 509
Shaft-hub: Surface pressure conical interference fits - Surface pressure serration profile
Bolted connection: Forces at the bolt - Preliminary design of bolted connections
Riveted and soldering joints
Bolts, pins: shear stress
Gearing: design of spur gear pair
Beams, frames: Buckling of beams - Statically determinate beam - Statically indeterminate beam - Round plates - Beam on elastic support - Frame - Beam with pendulum supports - Beams with longitudinal force - Coupled beams - Frame with gel. Coupling - Coupled column row - Collar beam roof - Selection of beam profiles - Strain calculation - Torsional surface moments of inertia
Clutch and brakes: Brakes
Overview of the basic modules for
MDESIGN technology
Hertzian pressure - Equivalent stress - Hardness values - Stress curve - General tolerance - Thermal expansion - ISO fitting system - Tolerance analysis - Pressure between bodies - Efficiency - Surface pressure - Cylindrical shell - Conical shell - Spherical shell - Rotationally symmetrical shell - Toroidal shell, membrane stress - Tube - Long conical shell - Cylindrical shell with ends - Bending and membrane stresses
Overview of the basic modules for
MDESIGN process
Apparatus, pipelines: Thick-walled cylindrical shell - Thick-walled spherical shell - Cylindrical shell, wall thickness - Cylindrical shell, stress
Hydraulics: Hydraulic press - water power - pump - pipe, Reynolds number - pipe, speed - oil viscosity - sealing surface pressure
Overview of the basic modules for
MDESIGN nature
Physics: deformable bodies - Hydrostatics and hydrodynamics - Kinematics - Dynamics - Gravitation - Rotational motion of rigid bodies - Damped mechanical oscillation - Superimposed oscillation - Undamped mechanical oscillation - Strain calculation - Mass moments of inertia - Surface moments of inertia - Axial mass moments of inertia - Axial surface moments of inertia - Pressure force, buoyancy
Geometry: Geometry data (2D) - Geometry data (3D) - Triangle calculation - Cross-section properties - Division of lengths
Dynamics: Torsional stress in a Shaft - Tension in a rope - Forces on hoists - Mechanical power during rotary motion - Inclined plane - Stresses in a bar
